Extended body posts for 1/10 Traxxas TRX-4m by JConcepts

5251 -

Installation notes:

To install the body mount system, it’s necessary to identify if you have a standard TRX-4M or High Trail variant. JConcepts has body mount bases for both types of trucks, and they are marked on the bottom as S for (Standard) and HT for (High Trail). The mounts are keyed for each shock tower individually and will need to be checked to make sure it drops down on each corner prior to locating screws.

Once the body mount bases are laid out for each corner, remove shock mounting screw from the top of the shock and add the mount base. Reinstall the included M2x13 BHCS through the shock eyelet and into the new mount base to secure the position. Add the long body mounts to each corner and set ride height according to where the user wants the position of the body to be relative to the tires. To maintain body mount height, add M2x8 BHCS through the mount base and into the mount post. It is now a good time to drop the body down onto the mounts and mark holes for the body mounts to stick through the polycarbonate body. Ream or drill the holes in the body carefully to just fit the diameter of the posts.

For final attachment, add body clips on top to secure the body to the mounts. Body clip leashes are also included to help keep the clips in order; these can be installed to user preference and position of choice. Once body height and position are finalized, come back and trim the extra body post material hanging from the bottom to help clean up the final look and finish. The mounts can be cut with hobby-based knife or curved hobby scissors.
